Antennes Qth. Aalst - gld , PD2BA . Ben

Mosley Pro 67-B 7el. 6 bander 10-12-15-17-20-40m and my homebrew Moxon beam 2el.for 20m.

Transceiver in used by PD2BA , Icom 7600

Icom 7600 , great transceiver , in used for SSB operation , Dig.modes and JT-65.

DU 1500 T , Antenne Tuner

A Look inside from my Antenne Tuners , made in Hungary.

UHF Antennes

Antennes in used for high Freq.

DU 1500 T , Antenne Tuner

Front look from my Antenne Tuner , made in Hungary

Helical duplex filter

Professional duplex filter for 70cm in used by PD2GA



Hello world!

Hello fellow Hams and ham radio listeners!

Get comfy and have fun surfing my site. You will probably have worked me if you visit this website, in that case I want to thank you very much for the contact.
Let me Introduce myself :

My name is Ben , Iam born on 23 april 1970 and I have my amateur license since 2002, living in the beautiful province gelderland (South) in the Netherlands. Qth: Aalst (Bommelerwaard),grid.Locator JO21NS . Amateur radio is one of my greatest hobby, I enjoy it already for many years and still do . I like the HF and VHF bands, so you can find me there most of the time on 10 – 20 or 40 meter.

I Like to operate JT 65 Mode , RTTY and SSB operation !

I hope to see you soon into my log for 2013 , hopefully you will enjoy my page. Qsl via bureau or direct or eQSL . ( no LOTW & no IRC’s pse, Member : VRZA – eQsl- Global Qsl )

www.hrdlog.net



WW2DX remote controle in Qso with PD2BA

eQSL design by PD2BA

Again another eQSL design !

This is my eQSL design for the moment.

Operation freq. for JT 65

JT65-HF — an ‘Odd’ but Fun Digital Mode

In case you’ve never seen it before, let’s explore a seemingly-little-known digital mode called JT65-HF. In some ways, it is very similar to other digital modes such as PSK31, but it some ways, it is very much different.

First, the similarities. The equipment required is the same as other digital modes, that is, the rig, the antenna, the computer with software, and a sound card interface. None of that will be new to you if you’ve ever done digital before.

It is also a low-power mode, even more so than PSK31. On the upper HF bands, you’ll often run 5W-10W or so. On the lower bands, 5W-10W will often do the trick, but for DX you might well crank it up to 30W-40W if really needed. Some JT65-HF users are committed to 5W max, period. It is important not to crank up the power too much because it will make it hard or impossible for others to hear weaker signals, just like on PSK31. In most cases, 10W will be sufficient. This is an extremely efficient weak-signal mode.
